DAYLIGHT TRAFFIC-(NIGHT TRAFFIC)
| . | ONE EAST | ONE WEST | TWO EAST | TWO WEST |
| *MAX L.O.A. | 170mt. (170 mt.) | 180mt. (170mt.) | 230mt. (230mt.) | 230mt. (230mt.) |
| *MAX BEAM | 30mt. | 30mt. | 39mt. | 39mt. |
| *MAX DRAFT | 35ft. | 35ft. | 39ft. | 39ft. |
| *NIGHT | YES | YES | YES | YES |
| *MAX S.D.W. | 33,000 | 33,000 | 60,000 | 60,000 |
| . | THREE EAST | THREE WEST(2) | FOUR EAST(2) | FOUR WEST |
| *MAX L.O.A. | 240mt. (230mt.) | 250mt. (230mt.) | 250mt (230mt.) | 230mt.(230mt.) |
| *MAX BEAM | 37mt. | 42mt. | 42mt | 42mt. |
| *MAX DRAFT | 39ft. | 39ft. | 39ft. | 39ft. |
| *NIGHT | YES | YES | YES | NO |
| *MAX S.D.W. | 72,000 | 82,000 | 72,000 | 72,000 |
| . | FIVE | SIX | SEVEN EAST/WEST | NINE EAST/WEST(1) |
| *MAX L.O.A. | 230mt.(230mt.) | 250mt. (230mt.) | 250mt. (230mt.) | 250mt.(230mt.) |
| *MAX BEAM | 42mt. | 42mt. | 42mt. | 42mt. |
| *MAX DRAFT | 39ft. | 39ft. | 39ft. | 39ft. |
| *NIGHT | NO | YES | YES | YES |
| *MAX S.D.W. | 60,000 | 80,000 | 82,000 | 82,000 |
(1)Use as laid bert (2)Maneuvers restricted if vessel of 250mt. L.O.A. and 42mt. BEAM is berthed in the opposite berth. |
||||
| (3):All vessels over 230 meters
LOA that enter and/or leave Pemex Pajaritos Terminal during nigthtime
(17:30 hrs to 07:00 hrs) will require the assistance of 2 pilots.
|
||||
